CARACTERÍSTICAS
Tamaño 22” class (21.5” diagonal)
Tipo LCD TV
Número Colores (Millones) 16.7 M
Formato 16:9
Resolución 1920x1080
Brillo (cd/m2) 250
Contrast Dinámico 50.000:1
Tiempo de respuesta 5ms
Ángulo de visión 170/160
Inverter(with/without) without
Surface Treatment(Glare/non Glare) non Glare
Conexiones
D-Sub Yes
DVI-D No
Composite Yes
S-Video No
Component No
SCART No
HDMI Yes
DisplayPort No
Others USB
[ Jack Location ] Rear
Audio Input
RCA Yes
PC Audio In No
Mic In
Others
[ Jack Location ] Rear
Audio Output
RCA
Headphone Out No
Line-out
Optical out
Others
[ Jack Location ]
Tuner Input
DVB
ATSC
NTSC(America/Korea)
NTSC(Japan)
PAL/SECAM
PAL Multi Yes
PAL M/N
Others
[ Jack Location ]
Speaker
Type Internal
Audio output 7W*2Ch
Others
Power
Type Built-in(LIPS)
Input 100~240V
Output(for Speaker) No

Normal On(Typ.) 30W
Power Save/Sleep Mode(Max) 1Watt (RGB)
DC Off(Max) 0.5Watt
Frequency
H-Frequency Analog 30kHz~69kHz
V-Frequency Analog 56Hz~61Hz

H-Frequency Digital
V-Frequency Digital
Resolution Input
Analog 1920x1080
Digital

HDMI 480p, 576p 720p, 1080i, 1080p
Component
Video NTSC, PAL
Control Key
Key Number (Power Key Included) 4 Key(Power, mode, , -)
Key Type Tact
LED Color(On mode) Blue
LED Color(Power save mode) BLANKING(BLUE)
[ Key Location ] Front right Side(Power), Rear side(Mode, , -)
OSD
Country
Number of Language 3ea(English, Spanish, Portuguese)
Special Features
Picture Mode vivid, standard, cinema
F-engine No
XD engine No
ARC-PC 4:3, 16:9
ARC-Video 16:9, 4:3, Zoom1, Zoom2, just scan
PIP No

SRS No
Dolby Surround No
AVL (Auto Volume) Yes
Equalizer No

sRGB No
DDC/CI No
HDCP Yes
Intelligent Auto (Auto Resolution) Yes
Remote Control Yes
EPG No
Teletext No
Caption Yes
CI Slot No
Deep Color(xvYCC) No
Key Lock Yes
Plug & Play DDC2B

Auto / Manual Clock Yes(Manual Clock)
On/ Off Time Yes
Sleep Timer Yes(Off/10min/20min/30min/60min/90min/120min/180min/240min / User)
Auto Off / Auto Sleep Yes

Hotel Mode No
TV Linker No
RS232C No
USB No
Color
Front Black Texture(Hair Line)
B/Cover Black Texture(MT11020)
Deco None
Stand Black Glossy
Base Black Glossy
Others None
Stand
Base Detchable Detachable
Tilt(Angle) None
Swivel(Angle) None
Height(mm) None
Pivot None
Dual Hinge None
Others None
Size (mm) / Weight
Set (with Stand) 520.8*166.39* 422.6
Set (without Stand) 520.8*61* 422.6
Box 594*472*140
Wall Mount VESA Compatible (75mm x 75mm)
only with respect to screw mounting interface dimensions
and mounting screw specifications
Set (with Stand) 3.6 kg
Set (without Stand) 3.4 kg
Box 5.4 kg.
Standard
TCO03 No
TCO99 No
UL(cUL) No
TUV-GS No
SEMKO No
FCC-B, CE No
Energy Star No
ISO13406-2 No
Medical Certificatioin No
Vista(Premium/Basic) Basic
Others
Accesory
Power Cord Yes
D-Sub Yes
DVI-D No
HDMI No
PC Audio No
RCA 3Line No
RCA 5Line No
Others Remote Controller, Battery
